FAZ-B3/2-NA - Eaton 3 Amp 2 Pole Miniature Circuit Breaker 277/480 VAC B Curve UL 489

FAZ-B3/2-NA

FAZ-B3/2-NA is an Eaton 3 Amp, 2 pole miniature circuit breaker designed for branch and control circuit protection.This Eaton FAZ-B3/2-NA is a thermal magnetic supplementary protector with a B curve trip characteristic, suitable for applications with low levels of inrush current. It features a 277/480 VAC voltage rating, 15 kA interrupt rating per IEC 60947-2, and is UL 489 and UL 1077 listed with CSA certification. The breaker mounts on DIN rail with standard screw terminals and provides reliable protection against wiring damage at low fault conditions.

• Amperage Rating: 3 Amp
• Number of Poles: Two Pole
• Voltage Rating: 277/480 VAC
• Interrupt Rating: 15 kAIC (IEC 60947-2)
• Trip Curve: B Curve (3-5x In instantaneous trip)
• Mounting Type: DIN Rail
• Standards: UL 489, UL 1077, CSA C22.2 No.235, IEC 60947-2
• Terminal Type: Screw Terminals
• Frequency Rating: 50-60 Hz
• Application: Supplementary Protector for low inrush current loads

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B3/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 3
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 01508129645
• GTIN : 04015081296453
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
