FAZ-B2/2-NA - Eaton 2A 2-Pole Thermal Magnetic Circuit Breaker 277/480V B Curve UL 489

FAZ-B2/2-NA

FAZ-B2/2-NA is a 2 Amp, 2-pole thermal magnetic circuit breaker from Eaton designed for branch circuit protection.FAZ-B2/2-NA features a B curve trip unit suitable for low inrush current applications, with a voltage rating of 277/480 VAC and interrupting capacity of 10-14 kAIC. It is UL 489 and CSA certified, mounts on DIN rail with screw terminals, and provides reliable protection in industrial and commercial electrical systems.

• Amperage Rating: 2 A
• Number of Poles: 2
• Voltage Rating: 277/480 VAC, 96 VDC
• Trip Curve: B Curve (Thermal Magnetic)
• Interrupt Rating: 10 kAIC UL/CSA, 14 kAIC IEC
• Mounting Type: DIN Rail
• Terminal Type: Screw
• Certifications: UL 489, CSA C22.2 No. 235
• Series/Frame: FAZ-NA
• Frequency: 50-60 Hz
• Application: Supplementary branch circuit protection with low inrush current
• Product Dimensions: Approx. 4.1 x 3 x 1.6 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B2/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 2
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 01508129644
• GTIN : 04015081296446
• Dimensions : 4.1 in x 3 in x 1.6 in (Length/Depth x Height x Width)
• Weight : 0.55
