FAZ-B16/3-NA - Eaton 16A 3-Pole 277/480VAC DIN Rail Mount Thermal Magnetic Circuit Breaker, FAZ Series, 14kAIC, UL/CSA/CCC/VDE

FAZ-B16/3-NA

FAZ-B16/3-NA is a 3-pole, 16A thermal magnetic miniature circuit breaker from Eaton, designed for reliable protection in industrial and commercial applications.

This circuit breaker features a DIN rail mounting type, feed-thru connection, and is part of the FAZ series. It offers both long-time and instantaneous (LI) protection, with an interrupting rating of 14kAIC at 480Y/277VAC. The FAZ-B16/3-NA is certified to UL 489, CSA, CCC, and VDE standards, ensuring compliance and safety across multiple regions.

Key Specifications
• Amperage: 16A
• Voltage: 277/480VAC, 96VDC
• Poles: 3
• Mounting Type: DIN Rail
• Interrupt Rating: 14kAIC @ 480Y/277VAC, 10kAIC
• Series/Frame: FAZ
• Trip Unit: Thermal Magnetic, B Curve (3-5x In)
• Certifications: UL, CSA, CCC, VDE, RoHS
• Connection: Feed-Thru
• Actuator Type: Handle/Lever
• Protection Functions: LI (Long Time and Instantaneous)
• Application: Industrial, commercial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B16/3-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 16
• Phase : 3
• Poles : 3
• AIC rating : 14kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 01508129673
• GTIN : 04015081296736
• Country of Origin : Germany
• Dimensions : 2.1 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 0.9
