FAZ-B16/2-NA - Eaton 16A 2-Pole Thermal Magnetic Circuit Breaker 277/480V B Curve 14kAIC DIN Rail

FAZ-B16/2-NA

FAZ-B16/2-NA is a 2-pole thermal magnetic miniature circuit breaker by Eaton designed for industrial branch protection applications.

This Eaton FAZ-B16/2-NA circuit breaker features a 16 ampere current rating and is rated for 277/480 volts AC operation. It has a B curve trip characteristic suitable for low inrush current applications and provides a 14 kA interrupting rating at 480Y/277 VAC. The breaker mounts on a 35mm DIN rail and uses screw terminals for secure wiring connections. It is UL 489 and CSA certified, ensuring compliance with industrial safety standards.

Key Specifications
• Amperage: 16 A
• Voltage Rating: 277/480 VAC
• Number of Poles: 2
• Trip Curve: B Curve (thermal magnetic)
• Interrupt Rating: 14 kAIC
• Mounting Type: 35mm DIN rail
• Terminal Type: Screw terminals
• Certifications: UL 489, CSA Std. C22.2 No. 235
• Frequency Rating: 50-60 Hz
• Trip Unit Type: Thermal magnetic (T17)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B16/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 16
• Phase : 1
• Poles : 2
• AIC rating : 14kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 01508129654
• GTIN : 04015081296545
• Dimensions : 1.4 in x 3 in x 1.6 in (Length/Depth x Height x Width)
• Weight : 0.6
