Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-B16/1-NA
FAZ-B16/1-NA is a 16 amp, 1-pole miniature circuit breaker from Eaton designed for industrial and commercial electrical protection.This thermal magnetic breaker features a B curve trip characteristic, 240 VAC/48 VDC voltage rating, and a 14kA interrupting rating at 240 VAC. It is current-limiting and mounts easily on a 35mm DIN rail. The breaker is UL 489 listed, HACR rated, reverse feed capable, and RoHS compliant, making it suitable for feeder and branch circuit protection.
- Amperage: 16A
- Voltage Rating: 240 VAC / 48 VDC
- Number of Poles: 1
- Trip Curve: B curve
- Trip Type: Thermal magnetic
- Interrupting Rating: 14kA @ 240 VAC
- Mounting Type: 35mm DIN rail
- UL Listed (UL 489)
- HACR Rated
- Reverse Feed Capable
- RoHS Compliant
- Series/Frame: Eaton FAZ Series
Specifications
- Part Number: FAZ-B16/1-NA
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ-NA
- Voltage : 480
- Amperage : 16
- Phase : 1
- Poles : 1
- AIC rating : 14kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 01508129635
- GTIN : 04015081296354
- Country of Origin : Germany
- Dimensions : 0.7 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
- Weight : 1
