FAZ-B15/2-NA - Eaton 15A 2-Pole 277/480VAC 96VDC Miniature Circuit Breaker, B Curve, Thermal Magnetic, 14kA Interrupt Rating, DIN Rail Mount, UL 489 Listed

FAZ-B15/2-NA

FAZ-B15/2-NA is an Eaton miniature circuit breaker designed for reliable protection in industrial and commercial applications.

This 2-pole, current-limiting circuit breaker features a 15A amperage rating, 277/480VAC and 96VDC voltage rating, and a B curve trip characteristic for optimized protection against overloads and short circuits. It is thermal magnetic, DIN rail mountable, and suitable for both feeder and branch circuits with low inrush current. The FAZ-B15/2-NA is UL 489 listed and CSA certified, ensuring compliance with North American safety standards.

Key Specifications
• Amperage: 15A
• Voltage: 277/480VAC, 96VDC
• Poles: 2
• Mounting Type: 35mm DIN rail
• Interrupt Rating: 14kA @ 240VAC
• Series/Frame: Eaton FAZ
• Trip Unit: Thermal magnetic, B curve
• Certifications: UL 489 listed, CSA certified
• Frequency: 50-60 Hz
• HACR Rated: Yes
• Reverse Feed Capable: Yes
• Operating Temperature: -25 to 75°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B15/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 14kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 001508129653
• GTIN : 04015081296538
• Country of Origin : Germany
• Dimensions : 3 in x 4.5 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 0.3 lb
• Certification : UL, CSA, IEC, CCC, VDE
