FAZ-B15/2 - Eaton 15A 480V Two-Pole B Curve UL 1077 Supplementary Protector Circuit Breaker

FAZ-B15/2

FAZ-B15/2 is a 15 Amp, two-pole, B curve supplementary protector circuit breaker from Eaton designed for low inrush current applications.This Eaton FAZ-B15/2 circuit breaker features a 15 kA interrupt rating, operates at 50-60 Hz frequency, and complies with UL 1077, CSA C22.2 No.235, and IEC 60947-2 certifications. It includes standard terminals and a thermal magnetic trip unit (T17) suitable for protecting wiring from low fault conditions. The compact device measures 3.5 in height, 3 in depth, and 1.5 in width, with a 1-year warranty.

• Amperage: 15 A
• Voltage Rating: Up to 480 VAC
• Poles: Two-pole
• Circuit Protection: B curve
• Interrupt Rating: 15 kAIC
• Frequency: 50-60 Hz
• Mounting Type: DIN rail
• Trip Unit: Thermal magnetic (T17)
• Terminals: Standard
• Certifications: UL 1077, CSA C22.2 No.235, IEC 60947-2
• Dimensions (HxWxD): 3.5 x 1.5 x 3 in
• Warranty: 1 year

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B15/2
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ
• Voltage : 480
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 4 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 015082787336
• GTIN : 04015082787332
• Country of Origin : Romania
• Dimensions : 3 in x 3.5 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 0.5
• Standards : CSA C22.2 No. 235, IEC 60947-2, UL 1077
• Certification : CSA C22.2 No. 235, IEC 60947-2, UL 1077
