Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-B1.5/2-NA
FAZ-B1.5/2-NA is a 2-pole miniature circuit breaker from Eaton designed for branch circuit protection with a 1.5 ampere rating and 277/480 volt AC operation.This Eaton FAZ-NA series breaker features a B curve thermal magnetic trip unit, suitable for low inrush current applications. It has a 10 kA interrupting rating at 277/480 VAC, complies with UL 489 and CSA certifications, and mounts on DIN rails for easy installation. The breaker supports wire sizes from 18 to 6 AWG and offers reliable current limiting protection.
- Amperage: 1.5 A
- Voltage Rating: 277/480 VAC
- Poles: 2
- Trip Curve: B Curve (3-5x In)
- Interrupt Rating: 10 kA
- Mounting Type: DIN Rail
- Series/Frame: FAZ-NA
- Certifications: UL 489, CSA Certified
- Wire Size Range: 18 to 6 AWG
- Operating Temperature: -25 to 75°C
- IP Rating: IP20
Specifications
- Part Number: FAZ-B1.5/2-NA
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ-NA
- Voltage : 480
- Amperage : 1.5
- Phase : 1
- Poles : 2
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 01508129643
- GTIN : 04015081296439
- Dimensions : 1.5 in x 3 in x 4.25 in (Length/Depth x Height x Width)
- Weight : 0.56
