Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-B1/1N
FAZ-B1/1N is an Eaton single-pole miniature circuit breaker designed for supplementary protection in applications with low inrush current.
This UL 1077 industrial miniature circuit breaker features a B curve trip characteristic, making it suitable for protecting sensitive equipment and wiring where low levels of inrush current are expected. It is DIN rail mounted, current limiting, and certified to UL 1077, CSA C22.2 No.235, and IEC 60947-2 standards for reliable circuit protection.
-
Key Specifications
- Amperage: 1A
- Voltage: 240V AC
- Poles: Single-pole
- Mounting Type: DIN rail
- Interrupt Rating: 15 kAIC
- Series/Frame: FAZ
- Trip Unit: B curve (3–5x In)
- Certifications: UL 1077, CSA C22.2 No.235, IEC 60947-2
- Frequency: 50–60 Hz
- Terminals: Standard
- Application: Supplementary protector for wiring and equipment
- Dimensions: 3.3" W x 2.9" H x 1.4" D
- Weight: 0.48 lb
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FAZ-B1/1N
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 2
- Amperage : 1
- Phase : 1
- Poles : 1
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 01508278633
- GTIN : 04015082786335
- Country of Origin : Germany
- Dimensions : 1.4 in x 2.9 in x 3.3 in (Length/Depth x Height x Width)
- Weight : 0.48
