FAP36025 - Square D 25A 600V 3 Pole Bolt-On Molded Case Circuit Breaker 18kA@480V

FAP36025

FAP36025 is a 3 pole, 600 Volt, 25 amp rated molded case circuit breaker manufactured by Square D. This breaker features a bolt-on mounting design and is suitable for a wide range of industrial and commercial applications. The FAP36025 is a thermal magnetic circuit breaker with long time and instantaneous trip functions. It is designed for use in 3 phase systems and includes line and load side lug terminals for easy installation. The breaker is rated for 18kA interrupting capacity at 480V and is built for reliable performance in demanding environments.

• Part Number: FAP36025
• Manufacturer: Square D
• Amperage: 25A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA@480V
• Series/Frame: FAP
• Trip Unit: Thermal Magnetic
• Application: 3 Phase
• Terminal Type: Line and Load Side Lug
• Function: Long Time and Instantaneous Trip

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAP36025
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAP Series
• Type : FAP
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901337867
• GTIN : 00785901337867
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 4.597
• Certification : CSA, UL
• Wire Size : AWG 14, AWG 4 Copper)1, AWG 12, AWG 4 Aluminium)1
