FA34060 - Square D 60 Amp 480VAC 3 Pole I-Line Molded Case Circuit Breaker F Frame

FA34060

FA34060 is a 3 pole, 60 amp, 480VAC molded case circuit breaker from Square D designed for I-Line mounting.This thermal magnetic circuit breaker features an 18kA interrupting rating at 480V, long-time and instantaneous trip functions (LI), and a plug-in I-Line style connection. It is UL and CSA certified and built on the FA series frame with load side lug terminals. The breaker is suitable for 3-phase power distribution applications and has a temperature rating of 40°C.

Key Specifications
• Amperage: 60 Amps
• Voltage: 480 VAC
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 18kA at 480V
• Series/Frame: FA Frame
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous)
• Certifications: UL, CSA
• Terminal Connection: Load Side Lug
• Dimensions (HxWxD): 6.4 x 4.5 x 4.13 inches
• Phase: 3
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FA34060
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 480
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782114793282
• GTIN : 00782114793282
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6.499
