FA32040 - Square D 40 Amp 240V 3 Pole I-Line Molded Case Circuit Breaker

FA32040

FA32040 is a 3 pole, 40 amp, 240V molded case circuit breaker from Square D designed for reliable power distribution protection.This Square D FA32040 circuit breaker features thermal magnetic protection with long-time and instantaneous trip functions. It has an I-Line style plug-in mounting type and a 10kA interrupting rating at 240V. The breaker is UL and CSA approved and rated for HACR applications with a 40°C temperature rating. It includes load side lug terminal connections and is designed for three-phase ABC wiring.

Key Specifications
• Manufacturer: Square D
• Series/Frame: FA
• Amperage: 40 Amps
• Voltage Rating: 240 VAC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 10kA at 240V
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous)
• Certifications: UL, CSA
• Terminal Connection: Load Side Lug
• Application: HACR Rated
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FA32040
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 240
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901422228
• GTIN : 00785901422228
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 9
