Square D EJB34030SA 30A 3-Pole E-Frame Miniature Circuit Breaker, 480Y/277V AC, 65kA, Bolt-On, Shunt Trip

EJB34030SA

Square D EJB34030SA 30A 3-Pole E-Frame Miniature Circuit Breaker, 480Y/277V AC, 65kA, Bolt-On, Shunt Trip

The Square D EJB34030SA is a Type EJB E-Frame miniature circuit breaker rated 30 A across three poles at a maximum operating voltage of 480Y/277 V AC, with a thermal-magnetic trip unit and a factory-installed shunt trip. Breaking capacity is 65 kA at 480Y/277 V AC and 100 kA at 120/240 V AC, and the device carries cULus certification with HID and HACR ratings.

Bolt-on construction locates the EJB34030SA in Square D NF panelboards, where the three-pole body and its shunt trip accessory together require four pole spaces. Aluminum lugs terminate AWG 12 to AWG 6 aluminum or AWG 14 to AWG 6 copper at 30.09 lbf-in.

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Common Applications

• Branch overload and short-circuit protection in Square D NF lighting panelboards
• High intensity discharge lighting circuits, per the HID rating
• Heating, air conditioning, and refrigeration circuits, per the HACR rating
• Circuits requiring remote or automatic opening from a 120 V AC control source

Key Features

• Thermal-magnetic trip unit: 875 A trip unit rating with a 270 A holding current.
• Factory-installed shunt trip: The SA suffix designates a 120 V AC shunt trip, 110-130 V AC control range, supplied factory-installed only.
• Trip indicator: Local signalling identifies the operated device at inspection.
• Aluminum lug terminations: AWG 12 to AWG 6 aluminum or AWG 14 to AWG 6 copper.

Specifications

• Brand: Square D (Schneider Electric)
• Catalog Number: EJB34030SA
• Product Type: Type EJB E-Frame miniature circuit breaker
• Range: 125 A Frame EDB-EGB-EJB
• Line Rated Current: 30 A
• Number of Poles: 3
• Maximum Operating Voltage: 480Y/277 V AC
• Breaking Capacity: 65 kA at 277 V AC and 480Y/277 V AC, 100 kA at 240 V AC, 120 V AC, and 120/240 V AC
• Breaking Capacity Code: J
• Trip Unit: Thermal-magnetic, 875 A rating, 270 A holding current
• Device Composition: Shunt trip
• Mounting Mode: Bolt-on, 4 pole spaces required
• Product Destination: NF panelboard
• Electrical Connection: Aluminum lugs, AWG 12 to 6 aluminum, AWG 14 to 6 copper
• Tightening Torque: 30.09 lbf-in (3.4 N.m)
• Ambient Calibration: 40 deg C (104 deg F)
• Certifications: cULus, HID rated, HACR rated

Product Identification

• Country of Origin: United States
• Product Size and Weight: 5.66 in H x 3.92 in W x 4.05 in D, 4 lb
• &


  Specifications

  • Part Number: EJB34030SA
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : EJB Series
  • Voltage : 480
  • Amperage : 30
  • Phase : 3
  • Poles : 3
  • AIC rating : 65kA@480V
  • Connection : Bolt-On
  • Functions : Long Time and Instantaneous Trip
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Thermal Magnetic



  Product Data

  • UPC : 785901594598
  • GTIN : 00785902000000
  • Country of Origin : Mexico
  • Dimensions : 5.66 in (143.76 mm) x 3.92 in (99.57 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Weight : 4.34 lb
  • Certification : CULus, UL, CSA
  • Wire Size : AWG 12 to AWG 6, AWG 14 to AWG 6, Aluminum/Copper
