EJB26090 - Square D 90A 2-Pole 600Y/347V E-Frame Molded Case Circuit Breaker Bolt-On

EJB26090

EJB26090 is a Square D molded case circuit breaker with a 90 amp rating, designed for 2-pole applications and bolt-on mounting.This E-Frame breaker supports a voltage rating of 600Y/347 VAC and features thermal-magnetic trip units. It has aluminum lugs compatible with AWG 12 to 2/0 aluminum and AWG 14 to 2/0 copper conductors. The breaker offers high interrupt ratings up to 100 kA at 240 V AC and is HACR rated for reliable protection in commercial and industrial panelboards.

Key Specifications
• Amperage: 90 Amp
• Poles: 2
• Voltage Rating: 600Y/347 VAC
• Frame/Series: E-Frame
• Mounting Type: Bolt-On
• Interrupt Rating: 25 kA @ 600Y/347 V AC, 65 kA @ 480Y/277 V AC, 100 kA @ 240 V AC
• Trip Unit: Thermal-Magnetic
• Lug Type: Aluminum
• Wire Range: AWG 12 to 2/0 Aluminum, AWG 14 to 2/0 Copper
• HACR Rated
• Local Signaling: Trip Indicator
• Certifications: UL Listed (US and Canada)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EJB26090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 606486143820
• GTIN : 03606490000000
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.54
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
