EJB26060 - Square D 60A 2 Pole 600V Bolt-On Circuit Breaker E-Frame Thermal Magnetic

EJB26060

EJB26060 is a Square D E-Frame 2 pole, 60 amp circuit breaker designed for bolt-on mounting in NF panelboards, providing reliable branch circuit protection. This molded case circuit breaker features a thermal-magnetic trip unit and is rated for 600V AC, making it suitable for a wide range of commercial and industrial applications. The breaker is compatible with aluminum and copper conductors and is calibrated for 40°C ambient temperature.

• 60 Amp amperage rating
• 2 pole configuration
• 600V AC voltage rating
• Bolt-on mounting type
• 65kA interrupt rating @ 480V
• E-Frame series
• Thermal-magnetic trip unit
• UL listed for use in Canada and US
• Compatible with NF panelboards
• Accepts AWG 12–6 aluminum and AWG 14–6 copper conductors

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB26060
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901506546
• GTIN : 00785901506546
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.54
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
