EJB26040 - Square D E-Frame Mini Circuit Breaker 40A 2-Pole 600Y/347V 25kA

EJB26040

EJB26040 is a Square D mini circuit breaker designed for industrial and commercial power distribution applications with thermal-magnetic trip protection. This E-frame breaker delivers reliable overcurrent protection in panelboard installations, featuring bolt-on mounting for quick and secure installation in compatible enclosures. The breaker is HACR rated and calibrated for 40 degrees C operation, making it suitable for demanding environments including lighting and branch circuit applications. Key Specifications

• Amperage Rating: 40 Amp
• Number of Poles: 2-Pole
• Voltage Rating: 600Y/347 VAC
• Interrupt Rating: 25 kA at 600Y/347 VAC; 65 kA at 480Y/277 VAC; 100 kA at 240 VAC
• Frame Type: E-Frame
• Mounting: Bolt-On
• Trip Mechanism: Thermal-Magnetic
• Terminal Lugs: Aluminum AWG 12 to AWG 2/0; Copper AWG 14 to AWG 2/0
• Certifications: UL, cULus
• Hold Current: 630A

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB26040
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 600
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901506577
• GTIN : 00785901506577
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.54
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
