EJB26020 - Square D 20A 2-Pole 600Y/347V E-Frame Bolt-On Circuit Breaker

EJB26020

EJB26020 is a Square D 20 Amp, 2-pole E-Frame circuit breaker designed for bolt-on mounting and rated for 600Y/347 volts.

This molded case circuit breaker features a 25 kA interrupt rating at 600Y/347 VAC and is HACR rated. It supports aluminum and copper lugs with wire size ranges from AWG 12 to AWG 6 aluminum and AWG 14 to AWG 6 copper. The breaker is calibrated for 40 degrees Celsius operation and is suitable for industrial and commercial electrical protection applications.

Key Specifications
• Amperage: 20 Amp
• Poles: 2
• Voltage Rating: 600Y/347 VAC
• Interrupt Rating: 25 kA @ 600Y/347 VAC
• Mounting Type: Bolt-On
• Frame/Series: E-Frame
• HACR Rated
• Lug Material: Aluminum and Copper
• Wire Size Range: AWG 12-6 Aluminum, AWG 14-6 Copper

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB26020
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901407034
• GTIN : 00785901407034
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.54
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 6 aluminum
  AWG 14...AWG 6 copper
