EJB24125 - Square D 125A 480Y/277V 2 Pole E-Frame Bolt-On Circuit Breaker

EJB24125

EJB24125 is a 125 amp, 2 pole molded case circuit breaker from Square D designed for bolt-on mounting and rated for 480Y/277 volts.EJB24125 features an E-Frame design with thermal-magnetic trip unit providing reliable short-circuit and overload protection. It has a maximum interrupt rating of 65kA at 480 volts and is suitable for branch circuit applications requiring UL certification.

• Amperage: 125A
• Voltage Rating: 480Y/277 VAC
• Number of Poles: 2
• Frame Type: E-Frame
• Mounting Type: Bolt-On
• Trip Unit: Thermal-Magnetic
• Interrupt Rating: 65kA at 480V
• Application: Branch Circuit Protection
• Certifications: UL Listed (US and Canada)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB24125
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 480
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901453345
• GTIN : 00785901453345
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.47
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12 to AWG 2/0, AWG 14 to AWG 2/0, Aluminum/Copper
