EJB24110 - Square D 110A 2-Pole 480V Bolt-On Molded Case Circuit Breaker

EJB24110

EJB24110 is a 2-pole, 480 volt, 110 ampere rated molded case circuit breaker designed for bolt-on installation in power distribution panels. This E-Frame breaker delivers reliable thermal-magnetic protection for branch circuit applications with an interrupt rating of 65 kA at 480V and 100 kA at 240V, making it suitable for demanding industrial and commercial environments. The breaker features aluminum lugs, HACR rating for air conditioning and refrigeration applications, and a trip indicator for visual fault confirmation.

• Amperage Rating: 110 Amps
• Voltage Rating: 480Y/277V AC
• Number of Poles: 2-Pole
• Mounting Type: Bolt-On
• Interrupt Rating: 65 kA @ 480V, 100 kA @ 240V
• Series: E-Frame
• Trip Unit: Thermal-Magnetic
• Lug Material: Aluminum
• HACR Rated: Yes
• Certifications: UL (Canada and US)
• Weight: 2.00 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB24110
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 480
• Amperage : 110
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901634706
• GTIN : 00785901634706
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.47
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12 to AWG 2/0 Aluminum, AWG 14 to AWG 2/0 Copper
