EJB14015EPD - Square D E-Frame 15A 1 Pole 277VAC Mini Circuit Breaker 100kA Max Bolt-On Mount 30mA Ground Fault

EJB14015EPD

EJB14015EPD is a Square D E-Frame miniature circuit breaker designed for reliable protection in commercial and industrial applications. This 1 pole, 15A, 277VAC breaker features a bolt-on mounting style and provides 30mA ground fault protection for enhanced safety. It is built with a robust interrupt rating and is suitable for use in a wide range of electrical systems. Engineered for durability and performance, the EJB14015EPD breaker offers thermal-magnetic tripping and is rated for use with copper and aluminum conductors. Its compact E-Frame design allows for efficient panel space utilization, and the device is HID rated for compatibility with high-intensity discharge lighting systems.

• Part Number: EJB14015EPD
• Manufacturer: Square D
• Series/Frame: E-Frame
• Amperage: 15A
• Voltage: 277VAC
• Poles: 1 Pole
• Mounting Type: Bolt-On
• Interrupt Rating: 100kA max at 120VAC
• Ground Fault Protection: 30mA
• Tripping Mechanism: Thermal-Magnetic
• Conductor Compatibility: AWG 14–6 copper, AWG 12–4 aluminum
• Application: HID rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB14015EPD
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 277
• Amperage : 15
• Phase : 1
• Poles : 1
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 3606486143728
• Country of Origin : Mexico
• Dimensions : 6.64 in (168.66 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.101
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 14...AWG 6 copper
  AWG 12...AWG 4 aluminum
