EHD3050 - Eaton 50A 480V 3-Pole F-Frame Molded Case Circuit Breaker Series C

EHD3050

EHD3050 is a 50 amp, 3-pole molded case circuit breaker from Eaton's Series C with an F-frame design for reliable circuit protection.This Eaton EHD3050 circuit breaker features a 480 Volt AC / 250 Volt DC rating, thermal magnetic trip unit, and bolt-on mounting. It has an interrupt rating of 18 kA at 240 VAC and 14 kA at 480 VAC, suitable for industrial and commercial applications. The breaker includes line and load side lug terminals and is UL listed for safety compliance.

Key Specifications
• Amperage: 50A
• Voltage: 480 VAC / 250 VDC
• Poles: 3
• Frame Type: F-Frame
• Series: Series C (EHD)
• Mounting Type: Bolt-On
• Interrupt Rating: 18 kA at 240 VAC, 14 kA at 480 VAC
• Trip Unit: Thermal Magnetic
• Phase: 3
• UL Listed
• Connection: Line & Load Lug Terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3050
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317143
• GTIN : 00786679317143
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
