EHD3020 - Cutler Hammer 20A 480V 3 Pole Molded Case Circuit Breaker, Series C, EHD Frame, Thermal Magnetic Trip, Bolt-On Mount, 14kAIC @ 480V, UL/CSA/CE

EHD3020

EHD3020 is a Cutler Hammer (Eaton) Series C molded case circuit breaker designed for industrial power distribution applications.

This three-pole, 20-ampere breaker features a thermal magnetic fixed trip unit, bolt-on mounting, and is rated for 480V AC (250V DC) with an interrupting capacity of 14kA at 480V AC (18kA at 240V AC). It is part of the EHD frame series, offering reliable protection for three-phase systems.

Key Specifications
• Part Number: EHD3020
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 20A
• Voltage: 480V AC, 250V DC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 14kAIC @ 480V AC, 18kAIC @ 240V AC
• Series/Frame: Series C, EHD Frame
• Trip Unit: Fixed Thermal Magnetic
• Certifications: UL, CSA, CE
• Dimensions: 4.13" W x 3.38" D x 6" H
• Weight: Approx. 4.15 lbs
• Application: Industrial, three-phase power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3020
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317068
• GTIN : 00786679317068
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.15
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
