EHD2080 - Cutler Hammer 80A 480V 2 Pole Molded Case Circuit Breaker Series C

EHD2080

EHD2080 is a Cutler Hammer 2 pole molded case circuit breaker rated for 80 amps and 480 volts, designed for reliable circuit protection.This Series C type EHD breaker features a thermal magnetic trip unit and a 14kA interrupt rating at 480VAC. It is bolt-on mounted and suitable for single-phase applications, providing robust performance in industrial and commercial electrical systems.

Key Specifications
• Amperage: 80 Amps
• Voltage: 480 Volts AC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 14kA at 480VAC
• Series/Frame: Series C, Type EHD
• Trip Unit: Thermal Magnetic
• Phase: Single Phase
• Standards: UL Listed, CSA Certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EHD2080
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC



Product Data

• UPC : 786679317570
• GTIN : 00786679317570
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
