Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD2030A06
EHD2030A06 is an Eaton Series C molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications. This two-pole breaker features fixed thermal and fixed magnetic trip protection with a 14 kAIC interrupt rating at 480 VAC, making it suitable for standard load switching and overcurrent protection. The F-frame design provides compact panel mounting with load-side lug terminals and includes a rear auxiliary switch rated at 1A-1B. Key Specifications
- Part Number: EHD2030A06
- Manufacturer: Eaton
- Amperage Rating: 30 A
- Voltage: 480 VAC / 250 VDC
- Number of Poles: 2
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 14 kAIC at 480 VAC, 18 kAIC at 240 VAC
- Series: Series C
- Frame Type: F-frame
- Mounting: Panel
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
- Dimensions: 6 IN H x 2.75 IN W x 3.38 IN D
Specifications
- Part Number: EHD2030A06
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
Product Data
- UPC : 786679096291
- GTIN : 00786679000000
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed
