EHD2025 - Westinghouse 25 Amp 2 Pole 480V Molded Case Circuit Breaker F-Frame Bolt-On

EHD2025

EHD2025 is a Westinghouse 2 pole, 25 amp molded case circuit breaker designed for industrial and commercial applications.This circuit breaker features a 480 volt rating, F-frame (Series C) design, bolt-on mounting, and a 14kA interrupt rating at 480V. It includes fixed thermal and magnetic trip units for reliable protection. The breaker is UL listed and suitable for load side connection.

Key Specifications
• Manufacturer: Westinghouse
• Part Number: EHD2025
• Amperage: 25 Amps
• Voltage: 480 Volts
• Poles: 2
• Frame Type: F-Frame (Series C)
• Mounting Type: Bolt-On
• Interrupt Rating: 14kA at 480V
• Trip Unit: Fixed Thermal and Magnetic
• Certifications: UL Listed
• Connection: Load Side
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EHD2025
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC



Product Data

• UPC : 786679317433
• GTIN : 00786679317433
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
