Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD1025L
EHD1025L is a Eaton Series C molded case circuit breaker designed for reliable single-pole protection with a 25 amp rating and 277/480 volt capacity.EHD1025L features a fixed thermal and magnetic trip unit (T186), F-frame design, and is UL Listed for safety and performance. It supports line and load busbar connections and is suitable for 50/60 Hz applications.
- Amperage: 25 Amp
- Poles: 1 (Single Pole)
- Voltage Rating: 277/480 VAC
- Series/Frame: Series C, F-Frame
- Trip Unit: Fixed Thermal Magnetic (T186)
- Interrupt Rating: 14 kA at 277 VAC
- Mounting Type: Busbar (Line and Load)
- Frequency: 50/60 Hz
- Certifications: UL Listed
- Dimensions: Approx. 6" Height, 3.38" Length, 1.38" Width
Specifications
- Part Number: EHD1025L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 277
- Amperage : 25
- Phase : 1
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 078667909820
- GTIN : 00786679098202
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 1.55 lb
