Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGS3030FFG
EGS3030FFG is a Cutler Hammer 3 pole molded case circuit breaker rated for 30 Amps and 600Y/347VAC voltage. It features thermal magnetic protection with fixed trip settings.
The EGS3030FFG belongs to the Eaton Series G EG-frame breakers and provides reliable circuit protection with a 35 kAIC interrupt rating at 480 VAC, 22 kAIC at 600Y/347 VAC, and 85 kAIC at 240 VAC. It includes long time and instantaneous trip functions and uses a feed-thru connection type. This breaker is designed for DIN rail mounting and is UL, IEC, and CSA certified for industrial and commercial applications.
- Key Specifications
- Amperage: 30 A
- Voltage Rating: 600Y/347 VAC
- Poles: 3
- Frame Type: EG (Series G)
- Interrupt Rating: 35 kAIC @ 480 VAC, 22 kAIC @ 600Y/347 VAC, 85 kAIC @ 240 VAC
- Trip Unit: Fixed Thermal Magnetic (Long Time and Instantaneous)
- Mounting Type: DIN Rail
- Connection Type: Feed-Thru (Line and Load)
- Certifications: UL, IEC, CSA
- Max Wire Size: 1/0 AWG
- Min Wire Size: 14 AWG
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: EGS3030FFG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGS
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous
- Terminal Connection : Line/Load Lug
- Frame Size : 125A/EG
- Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
- MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : ABC
Product Data
- UPC : 782114877111
- GTIN : 00782114877111
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 2.88
- Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
- Standards : CSA Certified, IEC Rated, UL Listed
- Certification : CSA Certified, IEC Rated, UL Listed
