EGS3025FFG - Cutler Hammer 3 Pole 25A 600V Series G Molded Case Circuit Breaker, Fixed Thermal Magnetic Trip, Feed-Thru Mounting, 35kA Interrupt Rating, UL Listed, CSA Certified

EGS3025FFG

EGS3025FFG is a Cutler Hammer Series G molded case circuit breaker designed for reliable protection in three-phase electrical systems.

This EG-frame circuit breaker features a fixed thermal magnetic trip unit, feed-thru connection, and is rated for 25A at 600Y/347V AC. It offers robust short-circuit protection with an interrupting capacity of 35kA at 480V, 22kA at 600Y/347V, and 85kA at 240V. The breaker is suitable for line and load applications, operates at 50/60 Hz, and is backed by major safety certifications.

Key Specifications
• Amperage: 25A
• Voltage: 600Y/347V AC
• Poles: 3
• Mounting Type: Feed-Thru
• Interrupt Rating: 35kA at 480V, 22kA at 600Y/347V, 85kA at 240V
• Series/Frame: Series G, EG-frame
• Trip Unit: Fixed thermal, fixed magnetic
• Connection: Line and load
• Frequency: 50/60 Hz
• Dimensions: 2.99" H x 5.5" W x 3" D
• Weight: 3 lb
• Certifications: UL Listed, CSA Certified, CE Marked, IEC Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGS3025FFG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGS
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782116131150
• GTIN : 00782116131150
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed,CSA Certified,IEC Rated,CE Marked
