EGS2060FFB - Cutler Hammer 60A 2 Pole 480V Bolt-On Molded Case Circuit Breaker 35kAIC Thermal Magnetic Trip

EGS2060FFB

EGS2060FFB is a Cutler Hammer 2 pole, 60 amp, 480 volt molded case circuit breaker with a 35kA interrupt rating and bolt-on mounting.This circuit breaker features a thermal magnetic trip unit with fixed long time and instantaneous trip functions. It is designed for 2-pole applications with line and load side lug terminals, suitable for industrial and commercial power distribution. The breaker is part of the EG frame series and meets UL 489, CSA, CE, and IEC certifications.

• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 60 A
• Voltage Rating: 480 VAC
• Poles: 2
• Interrupt Rating: 35kA @ 480 VAC
• Mounting Type: Bolt-On
• Trip Unit: Fixed Thermal Magnetic
• Frame Series: EG
• Terminal Type: Line & Load Side Lug
• Certifications: UL 489, CSA, CE, IEC
• Phase: Single Phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGS2060FFB
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGS
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685232676
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : UL Listed,IEC Rated,CSA Certified,CE Marked
