Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGS1040FFB
EGS1040FFB is a 1-pole, 40-amp molded case circuit breaker manufactured by Cutler Hammer (Eaton) designed for bolt-on installation in panelboards and load centers. This Series G circuit breaker provides reliable overcurrent protection for single-phase circuits at 240 volts with fixed thermal and fixed magnetic trip characteristics. The breaker features a compact EG frame design and is rated for 50/60 Hz operation, making it suitable for standard residential and light commercial applications requiring dependable circuit protection.
- Amperage Rating: 40 A
- Voltage Rating: 240 Vac
- Poles: 1
- Mounting Type: Bolt-On
- Series: G Series
- Frame: EG
- Trip Type: Fixed Thermal/Fixed Magnetic
- Interrupt Rating: 85 kA @ 240 Vac
- Frequency: 50/60 Hz
- UPC: 786685382012
Specifications
- Part Number: EGS1040FFB
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGS
- Voltage : 240
- Amperage : 40
- Phase : 1
- Poles : 1
- AIC rating : 85kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786685382012
- GTIN : 00786685382012
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 1 in (Length/Depth x Height x Width)
- Weight : 1.02
- Certification : IEC Rated,CSA Certified,UL Listed,CE Marked
