EGH2030FFG - Cutler Hammer 30 Amp 600Y/347 VAC 2-Pole EG Frame Molded Case Circuit Breaker G Series

EGH2030FFG

EGH2030FFG is a Cutler Hammer molded case circuit breaker from the G Series designed for reliable circuit protection.This 2-pole circuit breaker features a 30 amp rating and supports a maximum voltage of 600Y/347 VAC. It uses an EG frame with fixed thermal and fixed magnetic trip units, providing robust protection with interrupt ratings of 100 kA at 240 VAC, 65 kA at 480 VAC, and 35 kA at 600Y/347 VAC. The breaker is UL listed and suitable for line and load applications at 50/60 Hz.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: EGH2030FFG
• Series: G Series
• Frame Type: EG Frame
• Poles: 2
• Amperage: 30 Amp
• Voltage Rating: 600Y/347 VAC
• Interrupt Rating: 100 kA @ 240 VAC, 65 kA @ 480 VAC, 35 kA @ 600Y/347 VAC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting Type: Feed-Thru / DIN Rail Compatible
• UL Listed
• Frequency: 50/60 Hz
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EGH2030FFG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGH
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 786685018980
• GTIN : 00786685018980
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : IEC Rated,UL Listed,CSA Certified,CE Marked
