EGE3030FFG - Cutler Hammer 30A 600Y/347V 3-Pole EG-Frame Molded Case Circuit Breaker Fixed Thermal/Magnetic Trip

EGE3030FFG

EGE3030FFG is a Cutler Hammer molded case circuit breaker designed for reliable protection in electrical distribution systems.This 3-pole circuit breaker features a 30 ampere rating and operates at 600Y/347 volts AC. It belongs to the EG-frame series and includes a fixed thermal/magnetic trip unit for consistent performance. The breaker has an interrupt rating of 35 kAIC at 240 VAC and 25 kAIC at 600 VAC, suitable for demanding industrial and commercial applications. It is a bolt-on type mounting breaker with certifications ensuring safety and compliance.

Key Specifications
• Amperage: 30 A
• Voltage: 600Y/347 VAC
• Poles: 3
• Frame Type: EG-frame
• Trip Unit: Fixed Thermal/Magnetic
• Interrupt Rating: 35 kAIC at 240 VAC, 25 kAIC at 600 VAC
• Mounting Type: Bolt-On
• Series: Series G
• Frequency Rating: 50/60 Hz
• Certifications: UL Listed, CSA Certified (typical for Cutler Hammer/Eaton breakers)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EGE3030FFG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : EGE
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 125A/EG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC



Product Data

• UPC : 782114876718
• GTIN : 00782114876718
• Country of Origin : Dominican Republic
• Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
• Weight : 2.89
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
