Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGE3025FFG
EGE3025FFG is a three-pole molded case circuit breaker from Eaton's Series G line, designed for reliable protection in commercial and industrial applications. This breaker features a fixed thermal and fixed magnetic trip unit, providing precise overload and short-circuit protection. Rated for 25 amps and 600Y/347VAC, it is suitable for use in a wide range of electrical distribution systems. The breaker is built with an EG-frame and offers interrupt ratings up to 35 kAIC at 240VAC, 25 kAIC at 480VAC, and 18 kAIC at 600VAC. It is designed for feed-thru mounting and is certified for use in standard electrical panels.
- Part Number: EGE3025FFG
- Manufacturer: Eaton
- Series/Frame: Series G, EG-frame
- Amperage: 25 A
- Poles: 3
- Voltage Rating: 600Y/347 VAC
- Interrupt Rating: 35 kAIC @ 240VAC, 25 kAIC @ 480VAC, 18 kAIC @ 600VAC
- Mounting Type: Feed-Thru
- Protection Type: Fixed Thermal/Fixed Magnetic Trip
- Functions: LI (Long-Time and Instantaneous)
- Connection: Feed-Thru
- Certifications: UL Listed
Specifications
- Part Number: EGE3025FFG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGE
- Voltage : 600
- Amperage : 25
- Phase : 3
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous
- Terminal Connection : Line/Load Lug
- Frame Size : 125A/EG
- Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
- MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : ABC
Product Data
- UPC : 782116131396
- GTIN : 00782116131396
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 3
- Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
- Standards : CSA Certified, IEC Rated, UL Listed
- Certification : CSA Certified, IEC Rated, UL Listed
