EGB34125SA - Square D 125A 480Y/277VAC 3 Pole Bolt-On Thermal Magnetic Circuit Breaker EGB Series

EGB34125SA

EGB34125SA is a 3 pole, 125 amp thermal magnetic molded case circuit breaker from Square D's EGB series, designed for bolt-on mounting in panelboards.

This circuit breaker provides reliable overload and short circuit protection with a voltage rating of 480Y/277VAC and interrupting ratings of 35kA at 480Y/277VAC and 65kA at 120/240VAC. It features long-time and instantaneous trip functions, lug-type aluminum/copper terminals supporting AWG 12 to 2/0 wire sizes, and is UL and cULus listed for safety compliance. The breaker is suitable for use in lighting and NF panelboards and meets HACR standards.

Key Specifications
• Amperage: 125A
• Voltage Rating: 480Y/277VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupting Rating: 35kA at 480Y/277VAC, 65kA at 120/240VAC
• Series/Frame: EGB
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
• Terminal Connection: Lug-type for Aluminum and Copper
• Wire Gauge: AWG 12 to AWG 2/0
• Certifications: UL, cULus, HACR
• Phase: 3
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: EGB34125SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Type : EGB
• Voltage : 480
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901590217
• GTIN : 00785901590217
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 3.92 in (99.57 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 4.17
• Wire Size : AWG 12 to AWG 2/0, AWG 14 to AWG 2/0, Aluminum/Copper
