EGB34015AABA - Schneider Electric 15A 3-Pole 480Y/277V E-Frame Bolt-On Circuit Breaker

EGB34015AABA

EGB34015AABA is a 3-pole E-Frame mini circuit breaker rated at 15 amperes, 480Y/277V AC, designed for bolt-on installation in Square D NF panelboards. This thermal-magnetic trip unit breaker provides superior overload and short-circuit protection with a trip unit rating of 875 amperes and holding current of 270 amperes. The device features an auxiliary switch, alarm switch, and Visi-Trip indicator for fast troubleshooting. Key Specifications

• Part Number: EGB34015AABA
• Manufacturer: Schneider Electric
• Amperage: 15A
• Voltage: 480Y/277V AC
• Poles: 3
• Frame: E-Frame
• Mounting: Bolt-On
• Trip Unit Rating: 875A
• Holding Current: 270A
• Breaking Capacity: 35kA at 480Y/277V AC, 65kA at 240V AC, 65kA at 120V AC
• Trip Technology: Thermal-Magnetic
• Certifications: UL Listed, CSA, HOM Certified
• Wire Gauge: AWG 12-6 Aluminum, AWG 14-6 Copper

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB34015AABA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Voltage : 480
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 3.92 in (99.57 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 4.244
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 6 aluminum
  AWG 14...AWG 6 copper
