Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGB3050FFG
EGB3050FFG is a Cutler Hammer 3-pole molded case circuit breaker rated for 50 amps and 480 volts, designed for reliable branch circuit protection.This EG frame breaker features a fixed thermal and fixed magnetic trip unit, magnetic mounting, and an interrupt rating of 18 kA at 480 VAC and 25 kA at 240 VAC. It complies with UL 489, CSA 22.2, and IEC EN60898/60947-2 standards, making it suitable for industrial and commercial electrical applications.
- Manufacturer: Cutler Hammer (Eaton)
- Part Number: EGB3050FFG
- Frame Type: EG
- Amperage: 50A
- Voltage Rating: 480 VAC (600Y/347 VAC)
- Poles: 3
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting Type: Magnetic
- Interrupt Rating: 18 kA @ 480 VAC, 25 kA @ 240 VAC
- Certifications: UL 489, CSA 22.2, IEC EN60898/60947-2
- Terminals: Line and Load included
Specifications
- Part Number: EGB3050FFG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGB
- Voltage : 480
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 782114876367
- GTIN : 00782114876367
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 3 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed,IEC Rated,CSA Certified,CE Marked
