Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGB2060FFG
EGB2060FFG is a Cutler Hammer 2 pole, 60 amp, 480 Volt molded case circuit breaker from the EG Series designed for reliable circuit protection.This circuit breaker features a fixed thermal and fixed magnetic trip unit, suitable for panel mounting. It has an interrupt rating of 18 kAIC at 480 VAC and 25 kAIC at 240 VAC, supporting 50/60 Hz operation. The breaker is rated for line and load side lug terminals and is UL 489 certified.
- Manufacturer: Cutler Hammer (Eaton)
- Series/Frame: EG
- Poles: 2
- Amperage: 60 A
- Voltage: 480 VAC max (600Y/347 VAC)
- Interrupt Rating: 18 kAIC @ 480 VAC, 25 kAIC @ 240 VAC
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting Type: Panel Mount
- Frequency: 50/60 Hz
- UL Standard: UL 489
- Weight: 2 lbs
Specifications
- Part Number: EGB2060FFG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGB
- Voltage : 480
- Amperage : 60
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786685018508
- GTIN : 00786685018508
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
- Weight : 2
- Certification : CSA Certified,UL Listed,IEC Rated,CE Marked
