EGB16020 - Square D 20A 1-Pole 600Y/347VAC Miniature Circuit Breaker E-Frame Bolt-On

EGB16020

EGB16020 is a Square D 20 Amp, 1-pole miniature circuit breaker designed for reliable protection in electrical panelboards.This circuit breaker features a thermal-magnetic trip unit, E-frame construction, and bolt-on mounting type. It is rated for 600Y/347VAC operation with a high interrupt rating of up to 65kA at 120VAC. The breaker is UL and CSA certified and suitable for branch circuit protection in NF series panelboards.

• Amperage: 20 Amp
• Poles: 1 Pole
• Voltage Rating: 600Y/347VAC
• Interrupt Rating: 65kA @ 120VAC, 35kA @ 277VAC, 14kA @ 347VAC
• Frame/Series: E-Frame
• Trip Unit: Thermal-Magnetic
• Mounting Type: Bolt-On
• Certifications: UL, CSA
• Application: Branch Circuit Protection
• Panelboard Compatibility: NF Series

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB16020
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Type : EGB
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : G; E-Frame
• Temp Rating : 104 °F (40 °C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901238102
• GTIN : 00785901238102
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 0.98 in (24.89 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 1.35
• Panel Type : NF panelboard
• Standards : cULus
• Certification : cULus
• Wire Size : AWG 12...AWG 6 aluminum
  AWG 14...AWG 6 copper
