EGB16015 - Square D 15A 1 Pole 600Y/347V Bolt-On Mini Circuit Breaker E-Frame

EGB16015

EGB16015 is a Square D 15 Amp, 1 pole bolt-on mini circuit breaker designed for 600Y/347 Volt AC systems.This E-Frame breaker provides reliable overload and short circuit protection with a thermal-magnetic trip unit and a high interrupt rating suitable for lighting panelboards and other applications.

• Amperage: 15 Amp
• Voltage Rating: 600Y/347 VAC
• Number of Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 18 kA at 600V, 35 kA at 480Y/277V, 65 kA at 240V
• Series/Frame: E-Frame
• Trip Unit: Thermal-Magnetic
• Certifications: HACR Rated
• Wire Range: AWG 12-6 Aluminum, AWG 14-6 Copper
• Application: Lighting Panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EGB16015
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EGB Series
• Type : EGB
• Voltage : 600
• Amperage : 15
• Phase : 1
• Poles : 1
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : G; E-Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901235729
• GTIN : 00785901235729
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 0.98 in (24.89 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 1.36
• Panel Type : NF panelboard
• Standards : cULus
• Certification : cULus
• Wire Size : AWG 12 to AWG 6, Aluminum, AWG 14 to AWG 6, Copper
