EDH3225 - Cutler Hammer 225A 240V 3 Pole Bolt-On Circuit Breaker F Frame Series C

EDH3225

EDH3225 is a Cutler Hammer 3 pole, 225 amp, 240 volt bolt-on circuit breaker designed for reliable power distribution protection.This EDH3225 molded case circuit breaker features a Series C F-frame design with fixed thermal and magnetic trip units. It supports 240 VAC and 125 VDC operation with a 100kA interrupt rating at 240V. The breaker mounts via bolt-on panel installation and is UL listed for safety and performance.

• Amperage: 225A
• Voltage: 240 VAC, 125 VDC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 100kA at 240V
• Series/Frame: Series C, F Frame
• Trip Unit: Fixed Thermal Magnetic
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH3225
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078667945510
• GTIN : 00786679455104
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
• Wire Size : 4 to 4/0 AWG
