EDH2225 - Eaton 225A 240V 2-Pole F-Frame Series C Molded Case Circuit Breaker

EDH2225

EDH2225 is a 225 amp, 240 volt, 2-pole molded case circuit breaker from Eaton's Series C, F-frame line designed for reliable electrical protection.This Eaton EDH2225 circuit breaker features a fixed thermal magnetic trip unit, bolt-on mounting, and a 100 kA interrupt rating at 240 VAC. It is UL listed and suitable for use in 50 to 60 Hz electrical systems, with load side terminals and a compact design for efficient installation.

Key Specifications
• Amperage: 225 A
• Voltage Rating: 240 VAC, 125 VDC
• Number of Poles: 2
• Frame Type: F-Frame
• Series: Series C
• Trip Type: Fixed thermal magnetic
• Interrupt Rating: 100 kAIC at 240 VAC
• Mounting Type: Bolt-on
• Certifications: UL Listed
• Frequency Rating: 50 to 60 Hz
• Terminals: Load side
• Product Weight: Approx. 3 to 5 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2225
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 225
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456187
• GTIN : 00786679456187
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
