EDH2175 - Cutler Hammer 175A 2 Pole 240VAC Bolt-On Circuit Breaker, ED Frame, 100kAIC, Thermal Magnetic Trip

EDH2175

EDH2175 is a Cutler Hammer Series C molded case circuit breaker designed for reliable protection in commercial and industrial applications. This 2-pole, 175A breaker features a bolt-on mounting style, 240VAC/125VDC rating, and a robust 100kAIC interrupting capacity. The ED frame breaker uses a fixed thermal magnetic trip unit for precise overload and short-circuit protection. Suitable for reverse fed applications, it offers high interrupting capacity and load side lug terminals for secure connections. This breaker is ideal for panelboards and switchgear requiring dependable circuit protection. The molded case design ensures durability and safety, while the non-interchangeable trip unit prevents unauthorized modifications. UL listed for safety and performance.

• Part Number: EDH2175
• Manufacturer: Cutler Hammer
• Series: C
• Frame: ED
• Poles: 2
• Amperage: 175A
• Voltage: 240VAC, 125VDC
• Interrupt Rating: 100kAIC @ 240VAC
• Mounting: Bolt-On
• Connection: Load Side Lug Terminals
• Trip Unit: Fixed Thermal Magnetic
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH2175
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 175
• Phase : 2
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456309
• GTIN : 00786679456309
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
