EDCC20 - Edison Fuses 20 Amp 600V Class CC Time-Delay Fuse

EDCC20

EDCC20 is a 20 Amp, 600 Volt Class CC time-delay fuse from Edison Fuses designed for reliable circuit protection.This EDCC20 fuse features a current-limiting design with a 200kA interrupt rating at 600 VAC and 20kA at 300 VDC. It is a compact 1.5 inch long, 0.41 inch diameter ferrule-type fuse suitable for feeder and branch circuit protection. The time-delay characteristic helps prevent nuisance blowing from temporary overloads. It is UL listed, CSA certified, and meets Class CC standards for low voltage circuit protection.

• Amperage: 20 Amp
• Voltage Rating: 600 VAC, 300 VDC
• Fuse Type: Class CC
• Response Time: Time-Delay
• Interrupt Rating: 200kA RMS Symmetrical AC, 20kA DC
• Dimensions: 13/32 inch diameter x 1-1/2 inch length
• Mounting Type: Ferrule
• Certifications: UL Listed, CSA Certified
• Series: EDCC
• Current Limiting: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDCC20
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : EDCC Series
• Type : EDCC
• Voltage : 600
• Amperage : 20
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 782634808282
• GTIN : 00782634808282
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.19
