Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
EDCC10
EDCC10 is a Class CC, time-delay, current-limiting fuse designed for compact branch circuit protection up to 10 amps. This fuse features a ferrule mounting and is ideal for applications requiring fast response to short-circuit currents in a small footprint. The EDCC10 fuse is UL Listed and CSA Certified, providing reliable protection for feeder and branch circuits. Its compact size and rejection tip help prevent incorrect installation, while its high interrupt rating ensures safety in demanding environments.
- Amperage: 10A
- Voltage: 600VAC, 300VDC
- Interrupt Rating: 20kAIC
- Mounting Type: Ferrule
- Series: EDCC
- Time-Delay: Yes
- Current-Limiting: Yes
- Class: CC
- Physical Size: 13⁄32" x 1 1⁄2" (10.3 x 38.1mm)
- Rejection Tip: Yes
- Certifications: UL Listed, CSA Certified
- Application: Feeder/branch protection
Specifications
- Part Number: EDCC10
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : EDCC Series
- Type : EDCC
- Voltage : 600
- Amperage : 10
- AIC rating : 200kA@600V
- Diameter : 0.41
- Class Rating : CC
- Barrels : 1
Product Data
- UPC : 782634808251
- GTIN : 00782634808251
- Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
- Weight : 0.19
