EDB34045SA - Schneider Electric (Square D) 3-Pole 45 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

EDB34045SA

EDB34045SA - Schneider Electric E-Frame miniature circuit breaker with shunt trip, rated 45A, 3-pole, bolt-on mounting for NF panelboards.This thermal-magnetic circuit breaker provides overload and short-circuit protection for lighting panelboard applications. It features a 25kA interrupting capacity at 240VAC, 18kA at 480Y/277VAC, bolt-on mounting, aluminum/copper lugs, and trip indication. Designed as a branch circuit device with shunt trip functionality.

• Part Number: EDB34045SA
• Manufacturer: Schneider Electric (Square D)
• Amperage: 45A
• Number of Poles: 3
• Frame/Series: E-Frame / EDB
• Voltage Rating: 480Y/277 VAC
• Mounting Type: Bolt-on
• Trip Unit: Thermal-magnetic
• Interrupt Rating: 25kA @ 240VAC, 18kA @ 480Y/277VAC
• Device Composition: Shunt trip
• Application: NF panelboard, HACR/HID rated
• Certifications: cULus

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB34045SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901151043
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 3.92 in (99.57 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 4.21
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12 to 2/0 Aluminum, AWG 14 to 2/0 Copper
