EDB2225 - Cutler Hammer 225A 240V 2 Pole F-Frame Circuit Breaker Series C

EDB2225

EDB2225 is a Cutler Hammer 225 amp, 240 volt, 2 pole F-frame circuit breaker from the Series C family designed for reliable power distribution protection.This molded case circuit breaker features a fixed thermal and fixed magnetic trip unit, providing robust protection with a 22 kA interrupt rating at 240 VAC. It is suitable for 50/60 Hz applications and designed for Bolt-On mounting.

Key Specifications
• Amperage: 225A
• Voltage: 240 VAC, 125 VDC
• Poles: 2
• Frame Type: F-Frame
• Series: Series C
• Interrupt Rating: 22 kAIC at 240 VAC
• Trip Unit: Fixed thermal, fixed magnetic
• Mounting Type: Bolt-On
• Frequency: 50/60 Hz
• Certifications: UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EDB2225
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDB
• Voltage : 240
• Amperage : 30
• Phase : 2
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : F Frame
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic



Product Data

• UPC : 782116152582
• GTIN : 00782116152582
• Country of Origin : Mexico
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Standards : cULus, IEC
• Certification : cULus, IEC
