EDB2200 - Eaton 200 Amp 2 Pole 240V Series C F-Frame Molded Case Circuit Breaker, Bolt-On, 22kA Interrupt, Thermal Magnetic Trip, UL/CSA/CE

Name: EDB2200 - Eaton 200 Amp 2 Pole 240V Series C F-Frame Molded Case Circuit Breaker, Bolt-On, 22kA Interrupt, Thermal Magnetic Trip, UL/CSA/CE
Brand: Cutler Hammer
SKU: EDB2200-New
Price: 632.15 USD
Availability: InStock

Save $138.65

SKU: EDB2200-New

Condition: New

Variant

Price:

$632.15 $770.80

Stock:

Low inventory, please call for stock check
Factory Lead Time: 69 business days. Ships based on manufacturer availability when out of stock. All factory-ordered products are non-cancelable and non-returnable.

Quantity:

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

Enter your ZIP code:

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Manufacturer:Eaton
Sub-Category:Molded Case

EDB2200 - Eaton Bolt-On 240V 25A 2 pole circuit breaker 25kA@480V - Essential Electric Supply

EDB2200 - Eaton 200 Amp 2 Pole 240V Series C F-Frame Molded Case Circuit Breaker, Bolt-On, 22kA Interrupt, Thermal Magnetic Trip, UL/CSA/CE - Essential Electric Supply

Roll over image to zoom in Click on image to zoom Images are for reference only

EDB2200

EDB2200 - Eaton Series C F-frame molded case circuit breaker with fixed thermal-magnetic trip, 200A, 2-pole, 240VAC/125VDC rated.This complete Type ED breaker features panel or bolt-on mounting, load side terminals, and 22 kAIC interrupt rating at 240VAC for reliable circuit protection in industrial applications.

Part Number: EDB2200
Manufacturer: Eaton
Series: Series C
Frame: F-frame
Type: ED
Amperage: 200A
Poles: 2
Voltage AC: 240V
Voltage DC: 125V
Interrupt Rating: 22 kAIC @ 240VAC
Trip Type: Fixed thermal-magnetic
Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

Part Number: EDB2200
Manufacturer : Eaton
Brand : Cutler Hammer
Category : Circuit Breaker
Item Subcategory : Molded Case
Family : Series C
Type : EDB
Voltage : 240
Amperage : 25
Phase : 2
Poles : 2
AIC rating : 25kA@480V
Connection : Bolt-On
Functions : LI - Long-Time and Instantaneous
Terminal Connection : Lug
Frame Size : F Frame
Temp Rating : 104 ¡F (40 ¡C)
Protection : Thermal Magnetic

Product Data

UPC : 782116152605
GTIN : 00782116152605
Country of Origin : Mexico
Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
Weight : 3 lb
Standards : cULus, IEC
Certification : cULus, IEC

Accesories

Part	Manufacture	Sub Category
A1X1PK	Eaton	Auxiliary Switch
AAL1LPK	Eaton	Auxiliary
SNT1RP08K	Eaton	Shunt Trip
UVH1RP08K	Eaton	Under Voltage Release
A1X1LTK	Eaton	Auxiliary

Related Products

Part	Manufacture	Voltage	Amperage	Phase	AIC	Connection	Poles	Functions
edb2100	Cutler Hammer	240V	100	2	22kA@240V	Bolt-On	2	LI - Long-Time and Instantaneous
edb2125	Cutler Hammer	240V	125	2	22kA@240V	Feed-Thru	2	Long Time and Instantaneous Trip
edb2100l	Cutler Hammer	600V	20	2	25kA@480V	Feed-Thru	2	LI - Long-Time and Instantaneous
edb2100lbp10	Cutler Hammer	240V	20	2	22kA@240V	Feed-Thru	2	LI - Long-Time and Instantaneous
