EDB2150 - Cutler Hammer 2 Pole 150A 240VAC 125VDC Molded Case Circuit Breaker, Series C, F-Frame, Fixed Thermal/Magnetic Trip, 22kAIC, Panel Mount, UL Listed

EDB2150

EDB2150 is a Cutler Hammer (Eaton) Series C, F-frame molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This two-pole breaker features a fixed thermal/magnetic trip unit, 150A current rating, and is rated for 240VAC and 125VDC. It is panel-mounted, offers a 22kAIC interrupting rating at 240VAC, and is UL Listed for safety and compliance.

Key Specifications
• Part Number: EDB2150
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 150A
• Voltage: 240VAC, 125VDC
• Poles: 2
• Mounting Type: Panel
• Interrupt Rating: 22kAIC at 240VAC
• Series/Frame: Series C, F-frame
• Trip Unit: Fixed thermal, fixed magnetic
• Certifications: UL Listed
• Frequency: 50/60 Hz
• Connection: Load terminal
• Enclosure: NEMA AB1-1993

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB2150
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDB
• Voltage : 240
• Amperage : 150
• Phase : 2
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : F Frame
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782116152643
• GTIN : 00782116152643
• Country of Origin : Mexico
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Standards : cULus, IEC
• Certification : cULus, IEC
