Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
ED63B050L
ED63B050L is a Siemens 3-pole molded case circuit breaker designed for reliable protection in electrical systems.ED63B050L features a 50 amp trip rating with a 125 amp frame, suitable for 600V applications. It includes thermal and fixed magnetic trip units, line side lug mounting, and a standard interrupt rating of 25kA at 480VAC and 65kA at 240VAC. This breaker is part of the Siemens ED frame Sentron series and meets industry certifications for safety and performance.
- Key Specifications
- Amperage: 50 Amp trip, 125 Amp frame
- Voltage Rating: 600 VAC
- Poles: 3
- Interrupt Rating: 25kA @ 480VAC, 65kA @ 240VAC
- Mounting Type: Line side lug (lug not included)
- Trip Unit: Thermal and fixed magnetic
- Series/Frame: Siemens ED Frame Sentron
- Dimensions: Approx. 4" L x 6" W x 7" H
- Certifications: Industry standard safety certifications
Specifications
- Part Number: ED63B050L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 600 AC
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643236332
- GTIN : 00783643236332
- Country of Origin : Mexico
- Dimensions : 6.693 x 5.906 x 3.997
- Weight : 3.801
- Certification : Ul Listed, IEC
