Description
ED63A040
ED63A040 - Siemens 3-pole molded case circuit breaker rated at 40 Amps and 600 VAC.
Siemens ED63A040 is a Type ED frame, bolt-on mounted circuit breaker with thermal-magnetic trip protection, designed for reliable overcurrent protection in low voltage applications.
Key Specifications:
- Manufacturer: Siemens
- Frame Size: ED
- Amperage: 40A
- Voltage: 600 VAC / 250 VDC
- Poles: 3
- Mounting Type: Bolt-On
- Trip Unit: Instantaneous/Thermal-Magnetic
- Certifications: UL 489, CSA Listed
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: ED63A040
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 600 AC
- Amperage : 40
- Phase : 3
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : Instantaneous
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Magnetic Only
Product Data
- UPC : 783643214958
- GTIN : 00783643214958
- Country of Origin : Mexico
- Dimensions : 6.693 x 5.906 x 3.965
- Weight : 0.34
- Certification : IEC Certified, UL Listed
- Wire Size : AWG 10 to AWG 1/0, Cu/Al
